| Part Number | WEO001602GW |
| Mark | Winstar |
| Gréisst | 2.3 |
| Applikatioun | Instruments & Me |
| Opléisung | 5×8 |
| Zesummesetzung | OLED , PM-OLED |
| Hellegkeet | |
| CR | 2000:1 |
| Faarwen | Mono(White) |
| Géigeliicht | self |
| Interface | 8-bit |
| Fabrikant beschwéiert | Winstar |
| Modell Numm | WEO001602GW |
| Écran Gréisst | 2.3 inch |
| Écran Typ | OLED , PM-OLED |
| char Zuel | 16 characters × 2 lines 7PPI |
| char format | 5×8 dots |
| Char Pitch (mm) | 3.55×5.95 (H×V) |
| Char Gréisst (mm) | 2.97×5.57 (H×V) |
| aktiv Beräich (mm) | 56.22 × 11.52 (H×V) |
| Kontur (mm) | 79 × 44 × 9.67 (H×V×D) |
| Bezel Beräich (mm) | 58.22 × 13.52 (H×V) |
| Behandlung | - |
| luminance | - |
| Kontrast Verhältnis | 2000 : 1 (Typ.) (TM) |
| Vue Wénkel | 88/88/88/88 |
| Äntwert | 0.01 (Typ.) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | - |
| Faarfdéift | Mono(White) |
| mass | - |
| benotzt fir | Instruments & Meters |
| Erfrëschungsrate | - |
| touchscreen | Without |
| Chauffer ic Lëscht | Built-in COG SSD1311M1Z |
| Signal Typ | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 16 pins Pad |
| Spannungsversuergung | 3.3/5.0V (Typ.)(VDD) |
| AL1602B | Other | 2.3 | 16×2 |
| AMC162A | Other | 2.3 | 16×2 |
| AMC162B | Other | 2.3 | 16×2 |
| DMC-16202NY-LY-BJE-BLN | Kyocera | 2.3 | 16×2 |
| LS023B3UY01 | SHARP | 2.3 | 360×400 |
| TM023KDH60 | Tianma | 2.3 | 320×240 |
