| Part Number | WEH002004AB |
| Mark | Winstar |
| Gréisst | 2.9 |
| Applikatioun | Instruments & Me |
| Opléisung | 5×8 |
| Zesummesetzung | OLED, PM-OLED |
| Hellegkeet | |
| CR | |
| Faarwen | Mono(Blue) |
| Géigeliicht | self |
| Interface | CPU/SPI |
| Fabrikant beschwéiert | Winstar |
| Modell Numm | WEH002004AB |
| Écran Gréisst | 2.9 inch |
| Écran Typ | OLED, PM-OLED |
| char Zuel | 20 characters × 4 lines 7PPI |
| char format | 5×8 dots |
| Char Pitch (mm) | 3.54×5.4 (H×V) |
| Char Gréisst (mm) | 2.9×4.75 (H×V) |
| aktiv Beräich (mm) | 70.16 × 20.95 (H×V) |
| Kontur (mm) | 98 × 60 × 10 (H×V×D) |
| Bezel Beräich (mm) | 77 × 32 (H×V) |
| Behandlung | - |
| Vue Wénkel | - |
| Äntwert | - |
| gutt Vue op | Symmetry |
| Aarbecht Modus | - |
| Faarfdéift | Mono(Blue) |
| mass | - |
| benotzt fir | Instruments & Meters |
| Erfrëschungsrate | - |
| touchscreen | Without |
| Chauffer ic Lëscht | Built-in COB WS0010 |
| Signal Typ | CPU/SPI , Pad 16 pins |
| Spannungsversuergung | 5.0V (Typ.) |
