| Part Number | WEA012864DWPP3N00001 |
| Mark | Winstar |
| Gréisst | 0.96 |
| Applikatioun | Instruments & Me |
| Opléisung | 128×64 |
| Zesummesetzung | PM-OLED, OLED |
| Hellegkeet | |
| CR | |
| Faarwen | Mono(White) |
| Géigeliicht | self |
| Interface | 4-wire |
| Mark | Winstar |
| Modell | WEA012864DWPP3N00001 |
| diagonal Gréisst | 0.96 inch |
| Typ | PM-OLED, OLED |
| Pixel Format | 128×64 149PPI |
| Configuratioun | Rectangle |
| aktiv Beräich | 21.74(H)×10.86(V) mm |
| kontur dim. | 38(H)×28.5(V) ×4.37(D) mm |
| bezel Beräich | 23.94(H)×12.06(V) mm |
| Behandlung | - |
| Vue Richtung | Symmetry |
| Äntwert Zäit | - |
| Vue Wénkel | - |
| Betribssystemer Modus | - |
| Ënnerstëtzung Faarf | Mono(White) |
| Liichtquell | self |
| Gewiicht | - |
| entworf fir | Instruments & Meters |
| Frame Taux | - |
| Touch Panel | Without |
| d-ic detail | COG Built-in SSD1306BZ |
| Interface Typ | 4-wire SPI, I²C , 8 pins PIN |
| Stroumversuergung | 3.3/5.0/7.5V (Typ.) |
| Ëmwelt | Operating Temperature: -40 ~ 80 °C ; Storage Temperature: -40 ~ 85 °C |
