| Part Number | VTF231BJ02 |
| Mark | BOE |
| Gréisst | 23.1 |
| Applikatioun | Digital Signage Stre |
| Opléisung | 1920×158 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | BOE |
| Panel Modell | VTF231BJ02 |
| Panel Gréisst | 23.1" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 1920×158(RGB), 83PPI |
| Pixel Format | RGB Horizontal Stripe |
| Affichage Beräich | 585.216(W)×48.158(H) mm |
| bezel Ouverture | 587.5(W)×49.8(H) mm |
| Kontur Gréisst | 597.2(W)×60.2(H) ×17.1(D) mm |
| Uewerfläch | Antiglare (Haze 25%), Hard coating (3H) |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Display Modus | ADS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 15 (Typ.)(G to G) |
| weisen Faarwen | 16.7M 72% NTSC |
| Lampe Typ | WLED , 30K hours , With LED Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | 450g (Typ.) |
| Applikatioun | Digital Signage Stretched Bar LCD |
| Signal Interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Input Volt | 12.0V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| LQ231U1LW01 | SHARP | 23.1 | 1600×1200 |
| LQ231U1LW21 | SHARP | 23.1 | 1600×1200 |
