| Part Number | LQ231U1LW21 |
| Mark | SHARP |
| Gréisst | 23.1 |
| Applikatioun | IA |
| Opléisung | 1600×1200 |
| Zesummesetzung | LCM |
| Hellegkeet | 250 |
| CR | |
| Faarwen | 16.7M |
| Géigeliicht | CCFL |
| Interface | OpenLDI |
| Panel Mark | SHARP |
| Panel Modell | LQ231U1LW21 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 23.1 inch |
| Resolutioun | 1600(RGB)×1200 , UXGA |
| Display Modus | Transmissive |
| aktiv Beräich | 470.4×352.8 mm |
| skizzéieren | 530×432.8 mm |
| Uewerfläch | |
| Hellegkeet | 250 cd/m² (Typ.) |
| Kontrast Verhältnis | |
| weisen Faarwen | 16.7M (8-bit) |
| Äntwert Zäit | |
| Vue Wénkel | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| Lampe Typ | 6 pcsCCFLEmbedded (Inverter) |
| Signal Interface | OpenLDI |
| rohs: | |
| Applikatioun | IA |
