V420H2-LS2 Rev.C7

V420H2-LS2 Rev.C7
V420H2-LS2 Rev.C7
V420H2-LS2 Rev.C7
V420H2-LS2 Rev.C7 thumb V420H2-LS2 Rev.C7 thumb V420H2-LS2 Rev.C7 thumb
Mark
Innolux
Gréisst
42
Applikatioun
LCTV
Opléisung
1920×1080
Zesummesetzung
LCM
Hellegkeet
370
CR
5000:1
Faarwen
16.7M
Backlight
WLED
Interface
LVDS
In Stock
15342
Spezifikatioune

Part Number V420H2-LS2 Rev.C7
MarkInnolux
Gréisst42
ApplikatiounLCTV
Opléisung1920×1080
ZesummesetzungLCM
Hellegkeet370
CR5000:1
Faarwen16.7M
GéigeliichtWLED
InterfaceLVDS
Panel MarkCHIMEI INNOLUX
Panel ModellV420H2-LS2 Rev.C7
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst42 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusSuper MVA, Normally Black, Transmissive
aktiv Beräich930.24×523.26 mm
skizzéieren968.4×564×27.7 mm
UewerflächAntiglare (Haze 11%), Hard coating (3H)
Hellegkeet370 cd/m² (Typ.)
Kontrast Verhältnis5000:1 (Typ.)
weisen Faarwen16.7M (8-bit), CIE193172%
Äntwert Zäit6 (Typ.)(G to G)
Vue Wénkel88/88/88/88 (Typ.)(CR≥20)(L/R/U/D)
Frequenz120Hz (60Hz Input)
Lampe TypWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (2 ch, 8-bit), 61 pins
Input Volt12.0V (Typ.)
ApplikatiounLCTV
Famill Modell
LC420EUF-SCA1 LG Display 42 1920×1080
LC420WUF-SBN1 LG Display 42 1920×1080
T420HW09 V1 AUO 42 1920×1080
V420H2-L01 Innolux 42 1920×1080
V420H2-L02 Innolux 42 1920×1080
V420H2-L05 Innolux 42 1920×1080
V420H2-LE3 Innolux 42 1920×1080
V420H2-LN1 Innolux 42 1920×1080
V420H2-LS1 Innolux 42 1920×1080
V420H2-LS2 Rev.C7 Innolux 42 1920×1080
