| Part Number | TX20D202VM2BAA |
| Mark | HITACHI |
| Gréisst | 8.0 |
| Applikatioun | Industrial |
| Opléisung | 800×480 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 600:1 |
| Faarwen | 262K |
| Géigeliicht | , No Driver |
| Interface | LVDS |
| Fabrikant beschwéiert | HITACHI |
| Modell Numm | TX20D202VM2BAA |
| Écran Gréisst | 8.0 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 800(RGB)×480 (WVGA) 116PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 174 × 104.4 (H×V) |
| Kontur (mm) | - |
| Bezel Beräich (mm) | - |
| Behandlung | Antiglare |
| luminance | - |
| Kontrast Verhältnis | 600 : 1 (Typ.) (TM) |
| Vue Wénkel | - |
| Äntwert | - |
| gutt Vue op | - |
| Aarbecht Modus | TN, Normally White, Transmissive |
| Faarfdéift | 262K |
| mass | - |
| benotzt fir | Industrial |
| Signal Typ | LVDS |
