| Part Number | TV101WUM-NW1 |
| Mark | No Brand |
| Gréisst | 10.1 |
| Applikatioun | Pad & Tablet |
| Opléisung | 1200×1920 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | 8S4P |
| Interface | MIPI |
| Panel Mark | No Brand |
| Panel Gréisst | 10.1" |
| Resolutioun | 1200(RGB)×1920, WUXGA, 225PPI |
| Affichage Beräich | 135.36(W)×216.576(H) mm |
| Kontur Gréisst | 142.76(W)×228.18(H) ×4.2(D) mm |
| Hellegkeet | 450 cd/m² (Typ.) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M 100% sRGB |
| Frequenz | 60Hz |
| Panel Gewiicht | TBD |
| Signal Interface | MIPI (4 data lanes) , 40 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
| Panel Modell | TV101WUM-NW1 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | Clear, Hard coating |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Display Modus | HADS, Normally Black, Transmissive |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Lampe Typ | 8S4P WLED , Without Driver |
| Touchscreens | Without |
| Applikatioun | Pad & Tablet |
