| Part Number | TV101WUM-NH1 |
| Mark | BOE |
| Gréisst | 10.1 |
| Applikatioun | Pad & Tablet |
| Opléisung | 1200×1920 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | |
| Mark | BOE |
| diagonal Gréisst | 10.1 inch |
| Pixel Format | 1200(RGB)×1920 [WUXGA] 225PPI |
| aktiv Beräich | 135.36(H)×216.576(V) mm |
| bezel Beräich | - |
| luminance | 450 cd/m² (Typ.) |
| Vue Richtung | Symmetry |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| Ënnerstëtzung Faarf | 16.7M 100% sRGB |
| Gewiicht | 130g (Max.) |
| Frame Taux | 60Hz |
| Modell | TV101WUM-NH1 |
| Typ | a-Si TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 141.6(H)×227.41(V) ×3.8(D) mm |
| Behandlung | Hard coating (3H) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Äntwert Zäit | 25 (Typ.)(Tr+Tf) |
| Betribssystemer Modus | IPS, Normally Black, Transmissive |
| Liichtquell | WLED [8S4P] , W/O Driver |
| entworf fir | Pad & Tablet |
| Touch Panel | Without |
