| Part Number | TV101WUM-LL1 |
| Mark | BOE |
| Gréisst | 10.1 |
| Applikatioun | Pad & Tablet |
| Opléisung | 1200×1920 |
| Zesummesetzung | a-Si TFT-LCD , Assem |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | 8S4P |
| Interface | MIPI |
| Panel Mark | BOE |
| Panel Gréisst | 10.1" |
| Resolutioun | 1200(RGB)×1920, WUXGA, 225PPI |
| Affichage Beräich | 135.36(W)×216.576(H) mm |
| Kontur Gréisst | 162.1(W)×237.14(H) ×4.6(D) mm |
| Hellegkeet | 380 cd/m² (Typ.) |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M 99% sRGB |
| Frequenz | 60Hz |
| Panel Gewiicht | 190g (Typ.) |
| Signal Interface | MIPI (4 data lanes) , 45 pins Connector |
| Input Volt | 1.8/5.8/-5.8V (Typ.)(VDDI/AVDD/AVEE) |
| Ëmwelt | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
| Panel Modell | TV101WUM-LL1 |
| Panel Typ | a-Si TFT-LCD , Assembly |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | Hard coating |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Display Modus | - |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Lampe Typ | 8S4P WLED , Without Driver |
| Touchscreens | On-Cell Touch |
| Applikatioun | Pad & Tablet |
