| Part Number | TV097QXM-NW0 |
| Mark | BOE |
| Gréisst | 9.7 |
| Applikatioun | Pad & Tablet |
| Opléisung | 1536×2048 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1500:1 |
| Faarwen | 16.7M |
| Géigeliicht | 6S6P |
| Interface | MIPI |
| Panel Mark | BOE |
| Panel Modell | TV097QXM-NW0 |
| Panel Gréisst | 9.7" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 1536(RGB)×2048, QXGA, 264PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 147.456(W)×196.608(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 152.536(W)×206.548(H) ×4.5(D) mm |
| Uewerfläch | - |
| Hellegkeet | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 1500:1 (Typ.) (TM) |
| Vue Wénkel | 85/85/85/85 (Min.)(CR≥10) |
| Display Modus | ADS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 35 (Max.)(Tr+Td) |
| weisen Faarwen | 16.7M 70% NTSC |
| Lampe Typ | 6S6P WLED , Without Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | 135g (Max.) |
| Applikatioun | Pad & Tablet |
| Signal Interface | MIPI (4 data lanes) , 61 pins Connector |
| Input Volt | 1.8/5.5/-5.5V (Typ.)(VDDI/AVDD/AVEE) |
| Ëmwelt | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
| AM-1024768M2TMQW-T00H | AMPIRE | 9.7 | 1024×768 |
| HQ097QX1-IPS | Other | 9.7 | 2048×1536 |
| LP097QX1-SPA1 | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPAV | LG Display | 9.7 | 2048×1536 |
| LP097QX3-SPAV | LG Display | 9.7 | 1536×2048 |
| LP097X02-SLAA | LG Display | 9.7 | 1024×768 |
| LP097X02-SLN1 | LG Display | 9.7 | 1024×768 |
| LQ097L1JY02Z | SHARP | 9.7 | 2048×1536 |
| LTL097QL01-A01 | Samsung | 9.7 | 2048×1536 |
| LTN097QL01-A01 | Samsung | 9.7 | 2048×1536 |
