| Part Number | LQ097L1JY02Z |
| Mark | SHARP |
| Gréisst | 9.7 |
| Applikatioun | PAD |
| Opléisung | 2048×1536 |
| Zesummesetzung | LCM |
| Hellegkeet | |
| CR | |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | eDP |
| Panel Mark | SHARP |
| Panel Modell | LQ097L1JY02Z |
| Panel Typ | IGZO TFT-LCD , LCM |
| Panel Gréisst | 9.7 inch |
| Resolutioun | 2048(RGB)×1536 , QXGA |
| Display Modus | Normally Black, Transmissive |
| aktiv Beräich | 196.608×147.456 mm |
| Uewerfläch | |
| Hellegkeet | |
| Kontrast Verhältnis | |
| weisen Faarwen | 16.7M (8-bit) |
| Äntwert Zäit | |
| Vue Wénkel | |
| Frequenz | 60Hz |
| Lampe Typ | WLED |
| Signal Interface | eDP (4 Lanes) |
| Applikatioun | PAD |
