| Part Number | TV080WXM-NS1 |
| Mark | BOE |
| Gréisst | 8.0 |
| Applikatioun | Pad & Tablet |
| Opléisung | 800×1280 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1100:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | MIPI |
| Mark | BOE |
| diagonal Gréisst | 8.0 inch |
| Pixel Format | 800(RGB)×1280 [WXGA] 188PPI |
| aktiv Beräich | 107.64(H)×172.224(V) mm |
| luminance | 530 cd/m² (Typ.) |
| Vue Richtung | Symmetry |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Ënnerstëtzung Faarf | 16.7M 87% NTSC |
| Gewiicht | - |
| Frame Taux | 60Hz |
| Interface Typ | MIPI (4 data lanes) , 34 pins Connector |
| Stroumversuergung | 1.8/5.4/-5.4V (Typ.)(VDD1/PVDD/NVDD) |
| Ëmwelt | Operating Temperature: -20 ~ 65 °C ; Storage Temperature: -30 ~ 80 °C |
| Modell | TV080WXM-NS1 |
| Typ | a-Si TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 114.65(H)×183.853(V) ×3.56(D) mm |
| Kontrast Verhältnis | 1100:1 (Typ.) (TM) |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Betribssystemer Modus | ADS, Normally Black, Transmissive |
| Liichtquell | WLED [3 strings] , W/O Driver |
| entworf fir | Pad & Tablet |
| Touch Panel | Without |
