| Part Number | TM123XDHP90 |
| Mark | TIANMA |
| Gréisst | 12.3 |
| Applikatioun | Industrial Outdoor H |
| Opléisung | 1920×720 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | 10S4P |
| Interface | LVDS |
| Panel Mark | TIANMA |
| Panel Modell | TM123XDHP90 |
| Panel Gréisst | 12.3" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 1920(RGB)×720, 166PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 292.32(W)×109.62(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 311(W)×130(H) ×15.7(D) mm |
| Uewerfläch | Antiglare (Haze 28%) |
| Hellegkeet | 1000 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Wénkel | - |
| Display Modus | SFT, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| weisen Faarwen | 16.7M 98% sRGB |
| Lampe Typ | 10S4P WLED , 10K hours , Without Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | 490g (Typ.) |
| Applikatioun | Industrial Outdoor High Brightness Automotive Display |
| Signal Interface | LVDS (2 ch, 8-bit) , 50 pins FPC |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
