| Part Number | TM123XDHP01 |
| Mark | TIANMA |
| Gréisst | 12.3 |
| Applikatioun | Industrial Automotiv |
| Opléisung | 1920×720 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | |
| Mark | TIANMA |
| diagonal Gréisst | 12.3 inch |
| Pixel Format | 1920(RGB)×720 166PPI |
| aktiv Beräich | 292.32(H)×109.62(V) mm |
| luminance | - |
| Vue Richtung | Symmetry |
| Vue Wénkel | - |
| Ënnerstëtzung Faarf | 16.7M sRGB |
| Gewiicht | - |
| Frame Taux | 60Hz |
| Ëmwelt | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C |
| Modell | TM123XDHP01 |
| Typ | a-Si TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | - |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Betribssystemer Modus | SFT, Normally Black, Transmissive |
| Liichtquell | WLED |
| entworf fir | Industrial Automotive Display |
| Touch Panel | Without |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
