| Part Number | TM116VDSP03 |
| Mark | TIANMA |
| Gréisst | 11.6 |
| Applikatioun | Industrial Outdoor H |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 900:1 |
| Faarwen | 16.7M |
| Géigeliicht | 9S6P WLED , 50K hours , No Driver |
| Interface | LVDS |
| Fabrikant beschwéiert | TIANMA |
| Modell Numm | TM116VDSP03 |
| Écran Gréisst | 11.6 inch |
| Écran Typ | LCM , a-Si TFT-LCD |
| Pixel Zuel | 1920(RGB)×1080 (FHD) 190PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 256.32 × 144.18 (H×V) |
| Kontur (mm) | 273.5 × 166.5 × 11.5 (H×V×D) |
| Bezel Beräich (mm) | 259.31 × 148.73 (H×V) |
| Behandlung | Hard coating |
| luminance | 1000 cd/m² (Typ.) |
| Kontrast Verhältnis | 900 : 1 (Typ.) (TM) |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥10) |
| Äntwert | 25 (Typ.)(Tr+Td) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | SFT, Normally Black, Transmissive |
| Faarfdéift | 16.7M 70% NTSC |
| mass | TBD |
| benotzt fir | Industrial Outdoor High Brightness |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Signal Typ | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Spannungsversuergung | 3.3/10.7/20/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| max. Bewäertungen | Storage Temp.: -30 ~ 85 °C Operating Temp.: -20 ~ 70 °C |
