| Part Number | TM101DDHG05 |
| Mark | TIANMA |
| Gréisst | 10.1 |
| Applikatioun | Industrial |
| Opléisung | 1024×600 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | WLED |
| Interface | |
| Mark | TIANMA |
| diagonal Gréisst | 10.1 inch |
| Pixel Format | 1024(RGB)×600 [WSVGA] 117PPI |
| aktiv Beräich | 222.72(H)×125.28(V) mm |
| bezel Beräich | - |
| luminance | 1400 cd/m² (Typ.) |
| Vue Richtung | 12 o'clock |
| Vue Wénkel | 80/80/75/80 (Typ.)(CR≥10) |
| Ënnerstëtzung Faarf | 262K/16.7M 47% NTSC |
| Gewiicht | - |
| Frame Taux | 60Hz |
| Modell | TM101DDHG05 |
| Typ | a-Si TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 235(H)×143(V) ×7.8(D) mm |
| Behandlung | Antiglare, Hard coating |
| Kontrast Verhältnis | 500:1 (Typ.) (TM) |
| Äntwert Zäit | 7/9 (Typ.)(Tr/Td) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Liichtquell | WLED [14S3P] , 30K hours , W/O Driver |
| entworf fir | Industrial |
| Touch Panel | Without |
| AM-1280800N1TZQW-T06H | AMPIRE | 10.1 | 1280×800 |
| B101EW05 V0 | AUO | 10.1 | 1280×800 |
| BT101IW02 V.0 | Innolux | 10.1 | 1024×600 |
| CLAA101WJ06 | CPT | 10.1 | 1366×768 |
| HSD101PFW2-C00 | HannStar | 10.1 | 1024×600 |
| HSD101PWW1-H00 | HannStar | 10.1 | 1280×800 |
| LQ101K1LY02 | SHARP | 10.1 | 1280×800 |
| TM101DDHG01 | Tianma | 10.1 | 1024×600 |
| TM101DDHG03 | Tianma | 10.1 | 1024×600 |
| TM101JDHP01 | Tianma | 10.1 | 1280×800 |
