| Part Number | TM070DVHG01-41 |
| Mark | TIANMA |
| Gréisst | 7.0 |
| Applikatioun | Industrial |
| Opléisung | 1024×600 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 16.7M |
| Géigeliicht | 3S6P |
| Interface | |
| Panel Mark | TIANMA |
| Panel Gréisst | 7.0" |
| Resolutioun | 1024(RGB)×600, WSVGA, 169PPI |
| Affichage Beräich | 153.6(W)×90(H) mm |
| Kontur Gréisst | 171.5(W)×110.3(H) ×5.3(D) mm |
| Hellegkeet | 270 cd/m² (Typ.) |
| Vue Wénkel | 75/75/70/75 (Typ.)(CR≥10) |
| beschte Vue op | 12 o'clock |
| weisen Faarwen | 16.7M 50% NTSC |
| Frequenz | 60Hz |
| Gewiicht | - |
| Panel Modell | TM070DVHG01-41 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | - |
| Kontrast Verhältnis | 500:1 (Typ.) (TM) |
| Display Modus | TN, Normally White, Transmissive |
| Äntwert Zäit | 20 (Typ.)(Tr+Td) |
| Lampe Typ | 3S6P WLED , 20K hours , Without Driver |
| Touchscreens | PCAP |
| Applikatioun | Industrial |
