| Part Number | TM050RDZG03-30 |
| Mark | TIANMA |
| Gréisst | 5.0 |
| Applikatioun | Industrial |
| Opléisung | 800×480 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 600:1 |
| Faarwen | 16.7M |
| Géigeliicht | 3S6P WLED , 50K hours |
| Interface | |
| Fabrikant beschwéiert | TIANMA |
| Modell Numm | TM050RDZG03-30 |
| Écran Gréisst | 5.0 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 800(RGB)×480 (WVGA) 188PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 108 × 64.8 (H×V) |
| Kontur (mm) | 120.7 × 77.8 × 5.9 (H×V×D) |
| Bezel Beräich (mm) | 111.1 × 67.9 (H×V) |
| Behandlung | Antiglare, Hard coating (3H) |
| luminance | 1000 cd/m² (Typ.) |
| Kontrast Verhältnis | 600 : 1 (Typ.) (TM) |
| Vue Wénkel | 70/70/50/70 (Typ.)(CR≥10) |
| Äntwert | 20/30 (Typ./Max.)(Tr+Td) ms |
| gutt Vue op | 12 o'clock |
| Aarbecht Modus | TN, Normally White, Transmissive |
| Faarfdéift | 16.7M 50% NTSC |
| mass | TBD |
| benotzt fir | Industrial |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
| AT050TN33 | Innolux | 5.0 | 480×272 |
| DLC0500AIG-2 | Other | 5.0 | 640×480 |
| LD050WQ1-TD02 | LG Display | 5.0 | 480×272 |
| LQ050T5DG02 | SHARP | 5.0 | 400×240 |
| LS050T1SX12(K) | SHARP | 5.0 | 1080×1920 |
| LTE052T-45 | Philips | 5.0 | 320×234 |
| PA050XS7 | E Ink | 5.0 | 320×234 |
| TFD50W72MS | TOSHIBA | 5.0 | |
| TM050JVZG28 | Tianma | 5.0 | 720×1280 |
| TM050RDH03 | Tianma | 5.0 | 800×480 |
