| Part Number | TM050RDH03-00 |
| Mark | TIANMA |
| Gréisst | 5.0 |
| Applikatioun | Industrial Portable |
| Opléisung | 800×480 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 600:1 |
| Faarwen | 16.7M |
| Géigeliicht | 7S2P |
| Interface | Parallel |
| Panel Mark | TIANMA |
| Panel Modell | TM050RDH03-00 0 Compatible |
| Panel Gréisst | 5.0" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 800(RGB)×480, WVGA, 188PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 108(W)×64.8(H) mm |
| bezel Ouverture | 111.1(W)×67.9(H) mm |
| Kontur Gréisst | 120.7(W)×75.8(H) ×3.1(D) mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 250 cd/m² (Typ.) |
| Kontrast Verhältnis | 600:1 (Typ.) (TM) |
| Vue Wénkel | 70/70/50/70 (Typ.)(CR≥10) |
| Display Modus | TN, Normally White, Transmissive |
| beschte Vue op | 12 o'clock |
| Äntwert Zäit | 20 (Typ.)(Tr+Td) |
| weisen Faarwen | 16.7M 50% NTSC |
| Lampe Typ | 7S2P WLED , 20K hours , Without Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | TBD |
| Applikatioun | Industrial Portable Navigation MID UMPC MP3 PMP |
| Signal Interface | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
