| Part Number | TM028HDZ58 |
| Mark | TIANMA |
| Gréisst | 2.8 |
| Applikatioun | Mobile Phone |
| Opléisung | 240×320 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 65K/262K |
| Géigeliicht | 1S4P WLED , No Driver |
| Interface | Parallel |
| Fabrikant beschwéiert | TIANMA |
| Modell Numm | TM028HDZ58 |
| Écran Gréisst | 2.8 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 240(RGB)×320 (QVGA) 141PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 43.2 × 57.6 (H×V) |
| Kontur (mm) | - |
| luminance | - |
| Kontrast Verhältnis | 500 : 1 (Typ.) (TM) |
| Vue Wénkel | 60/60/60/50 (Typ.)(CR≥10) |
| Äntwert | 25 (Typ.)(Tr+Td) ms |
| gutt Vue op | 6 o'clock |
| Aarbecht Modus | TN, Normally White, Transmissive |
| Faarfdéift | 65K/262K 55% NTSC |
| mass | - |
| benotzt fir | Mobile Phone |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Signal Typ | Parallel RGB (1 ch, 6-bit) + SPI |
| max. Bewäertungen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| 28QVF1H | SII | 2.8 | 240×320 |
| ET028002DHU | EDT | 2.8 | 240×320 |
| LMS283GF11 | Samsung | 2.8 | 240×320 |
| LS028B8PX05 | SHARP | 2.8 | 240×400 |
| LTE283QV-F01 | Samsung | 2.8 | 320×240 |
| LTP283QV-F04 | Samsung | 2.8 | 240×320 |
| TM028HBHG02 | Tianma | 2.8 | 240×320 |
| TM028HDH21 | Tianma | 2.8 | 240×320 |
| TM028LDH01 | Tianma | 2.8 | 240×400 |
| TM028LDZ09 | Tianma | 2.8 | 240×400 |
