| Part Number | TM026HDH02 |
| Mark | TIANMA |
| Gréisst | 2.6 |
| Applikatioun | Mobile Phone |
| Opléisung | 240×320 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 65K/262K |
| Géigeliicht | WLED , No Driver |
| Interface | |
| Fabrikant beschwéiert | TIANMA |
| Modell Numm | TM026HDH02 |
| Écran Gréisst | 2.6 inch |
| Écran Typ | LCM , a-Si TFT-LCD |
| Pixel Zuel | 240(RGB)×320 (QVGA) 156PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 38.88 × 51.84 (H×V) |
| Kontur (mm) | - |
| luminance | 240 cd/m² (Typ.) |
| Kontrast Verhältnis | 500 : 1 (Typ.) (TM) |
| Vue Wénkel | 70/70/70/60 (Typ.)(CR≥10) |
| Äntwert | 25 (Typ.)(Tr+Td) ms |
| gutt Vue op | 6 o'clock |
| Aarbecht Modus | TN, Normally White, Transmissive |
| Faarfdéift | 65K/262K 60% NTSC |
| mass | TBD |
| benotzt fir | Mobile Phone |
| Erfrëschungsrate | - |
| touchscreen | Without |
| max. Bewäertungen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 60 °C |
| A026EAN01.0 | AUO | 2.6 | 800×1280 |
| AMDM001 | Samsung | 2.6 | 240×400 |
| AMS260CM61 | Samsung | 2.6 | 240×320 |
| L5F30774P01 | Epson | 2.6 | 240×320 |
| LS026B8PX04 | SHARP | 2.6 | 240×400 |
| LS026Q3DX01 | SHARP | 2.6 | 240×320 |
| LS026Q7UX01 | SHARP | 2.6 | 320×240 |
| TD026TTEA1 | TPO | 2.6 | 480×640 |
