TCG121XGLPBPNN-AN40-S

TCG121XGLPBPNN-AN40-S
TCG121XGLPBPNN-AN40-S
TCG121XGLPBPNN-AN40-S
TCG121XGLPBPNN-AN40-S thumb TCG121XGLPBPNN-AN40-S thumb TCG121XGLPBPNN-AN40-S thumb
Mark
Kyocera
Gréisst
12.1
Applikatioun
Industrial Outdoor H
Opléisung
1024×768
Zesummesetzung
a-Si TFT-LCD, LCM
Hellegkeet
CR
600:1
Faarwen
262K/16.2M
Backlight
WLED
Interface
LVDS
In Stock
2834
Spezifikatioune

Part Number TCG121XGLPBPNN-AN40-S
MarkKyocera
Gréisst12.1
ApplikatiounIndustrial Outdoor H
Opléisung1024×768
Zesummesetzunga-Si TFT-LCD, LCM
Hellegkeet
CR600:1
Faarwen262K/16.2M
GéigeliichtWLED
InterfaceLVDS
Panel MarkKyocera
Panel ModellTCG121XGLPBPNN-AN40-S
Panel Gréisst12.1"
Panel Typa-Si TFT-LCD, LCM
Resolutioun1024(RGB)×768, XGA, 105PPI
Pixel FormatRGB Vertical Stripe
Affichage Beräich245.76(W)×184.32(H) mm
bezel Ouverture249.0(W)×187.5(H) mm
Kontur Gréisst260.5(W)×203(H) ×10.9(D) mm
UewerflächAntiglare
Hellegkeet780 cd/m² (Typ.)
Kontrast Verhältnis600:1 (Typ.) (TM)
Vue Wénkel85/85/85/85 (Typ.)(CR≥10)
Display ModusAWV, Normally Black, Transmissive
beschte Vue opSymmetry
Äntwert Zäit18/12 (Typ.)(Tr/Td)
weisen Faarwen262K/16.2M   51% NTSC
Lampe TypWLED , 50K hours , With LED Driver
Frequenz60Hz
TouchscreensWithout
Panel Gewiicht555g
ApplikatiounIndustrial Outdoor High Brightness
Signal InterfaceLVDS (1 ch, 6/8-bit) , 20 pins Connector
Input Volt3.3V (Typ.)
ËmweltOperating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C
Famill Modell
AA121SJ23 Mitsubishi 12.1 800×600
B121EW09 V4 AUO 12.1 1280×800
HV121WX5-113 HYDIS 12.1 1280×800
LQ121S1DC71 SHARP 12.1 800×600
LQ121X1LH73 SHARP 12.1 1024×768
LTD121C32S TOSHIBA 12.1 800×600
LTD121EA3P TOSHIBA 12.1 1024×768
LTD121EXPD TOSHIBA 12.1 1280×800
NL10276BC24-19D NLT 12.1 1024×768
TCG121XGLPAPNN-AN20 Kyocera 12.1 1024×768
