AUO T650HVN07.3 Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


T650HVN07.3

T650HVN07.3
T650HVN07.3
T650HVN07.3
T650HVN07.3 thumb T650HVN07.3 thumb T650HVN07.3 thumb
Mark
AUO
Gréisst
65
Applikatioun
LCTV
Opléisung
1920×1080
Zesummesetzung
LCM
Hellegkeet
350
CR
4000:1
Faarwen
16.7M
Backlight
WLED
Interface
LVDS
In Stock
6204
Spezifikatioune

Part Number T650HVN07.3
MarkAUO
Gréisst65
ApplikatiounLCTV
Opléisung1920×1080
ZesummesetzungLCM
Hellegkeet350
CR4000:1
Faarwen16.7M
GéigeliichtWLED
InterfaceLVDS
Panel MarkAUO
Panel ModellT650HVN07.3
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst65 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusAMVA3, Normally Black, Transmissive
aktiv Beräich1428.48×803.52 mm
skizzéieren1454.3×831.5×33.6 mm
UewerflächAntiglare (Haze 2%), Hard coating (3H)
Hellegkeet350 cd/m² (Typ.)
Kontrast Verhältnis4000:1 (Typ.)
weisen Faarwen16.7M (8-bit), CIE193172%
Äntwert Zäit6.5(Typ.)(G to G)
Vue Wénkel89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe TypWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (2 ch, 8-bit), 51 pins
Input Volt12.0V (Typ.)
ApplikatiounLCTV
Famill Modell
T650HVD01.0 AUO 65 1920×1080
T650HVF03.0 AUO 65 1920×1080
T650HVJ02.0 AUO 65 1920×1080
T650HVJ02.1 AUO 65 1920×1080
T650HVN04.0 AUO 65 1920×1080
T650HVN04.1 AUO 65 1920×1080
T650HVN05.4 AUO 65 1920×1080
T650HVN05.9 AUO 65 1920×1080
T650HVN06.0 AUO 65 1920×1080
T650HVN07.3 AUO 65 1920×1080
