| Part Number | T645HW02 V5 |
| Mark | AUO |
| Gréisst | 65 |
| Applikatioun | LCTV |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM |
| Hellegkeet | 450 |
| CR | 4000:1 |
| Faarwen | 1.07B |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | AUO |
| Panel Modell | T645HW02 V5 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 65 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | AMVA3, Normally Black, Transmissive |
| aktiv Beräich | 1428.48×803.52 mm |
| skizzéieren | 1508×878 mm |
| Uewerfläch | Antiglare (Haze 2%), Hard coating (3H) |
| Hellegkeet | 450 cd/m² (Typ.) |
| Kontrast Verhältnis | 4000:1 (Typ.) |
| weisen Faarwen | 1.07B (8-bit + Hi-FRC), CIE193172% |
| Äntwert Zäit | 5.5 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 120Hz |
| Lampe Typ | CCFLEmbedded (Inverter) |
| Signal Interface | LVDS (4 ch, 10-bit), 92 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | LCTV |
| HV650QUB-B00 | BOE | 65 | 3840×2160 |
| LC650EQF-FJM1 | LG Display | 65 | 3840×2160 |
| P645HW01 V0 | AUO | 65 | 1920×1080 |
| T645HB01 V0 | AUO | 65 | 1920×1080 |
| T645HF02 V1 | AUO | 65 | 1920×1080 |
| T645HW02 V3 | AUO | 65 | 1920×1080 |
| T645HW02 V5 | AUO | 65 | 1920×1080 |
| T645HW04 V0 CELL | AUO | 65 | 1920×1080 |
| T645HW05 V0 | AUO | 65 | 1920×1080 |
| T650HVN07.0 | AUO | 65 | 1920×1080 |
| HV480FH2-600 | BOE | 48 | 1920×1080 |
| LC370WUG-SCA2 | LG Display | 37 | 1920×1080 |
| LC420DUE-SFR2 | LG Display | 42 | 1920×1080 |
| LC470DUE-FGA3 | LG Display | 47 | 1920×1080 |
| LC650DUF-FGF1 | LG Display | 65 | 1920×1080 |
| LSC460HN05-W | Samsung | 46 | 1920×1080 |
| LTA460HB03 | Samsung | 46 | 1920×1080 |
| V260B1-L11 | Innolux | 26.0 | 1366×768 |
| V315H3-L01 | Innolux | 31.5 | 1920×1080 |
| V580HJ1-PD6 | Innolux | 58 | 1920×1080 |
