AUO T315HW05 V0 Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


T315HW05 V0

T315HW05 V0
T315HW05 V0
T315HW05 V0
T315HW05 V0 thumb T315HW05 V0 thumb T315HW05 V0 thumb
Mark
AUO
Gréisst
31.5
Applikatioun
LCTV
Opléisung
1920×1080
Zesummesetzung
LCM
Hellegkeet
450
CR
4000:1
Faarwen
1.07B
Backlight
WLED
Interface
LVDS
In Stock
10
Spezifikatioune

Part Number T315HW05 V0
MarkAUO
Gréisst31.5
ApplikatiounLCTV
Opléisung1920×1080
ZesummesetzungLCM
Hellegkeet450
CR4000:1
Faarwen1.07B
GéigeliichtWLED
InterfaceLVDS
Panel MarkAUO
Panel ModellT315HW05 V0
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst31.5 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusAMVA3, Normally Black, Transmissive
aktiv Beräich698.4×392.85 mm
skizzéieren741.4×435.8 mm
UewerflächAntiglare, Hard coating (3H)
Hellegkeet450 cd/m² (Typ.)
Kontrast Verhältnis4000:1 (Typ.)
weisen Faarwen1.07B (8-bit + Hi-FRC), CIE193172%
Äntwert Zäit6.5 (Typ.)(G to G)
Vue Wénkel89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
Frequenz120Hz
Lampe TypWLEDEmbedded (LED Driver)
Signal InterfaceLVDS (4 ch, 10-bit), 92 pins
Input Volt12.0V (Typ.)
ApplikatiounLCTV
Famill Modell
T315HB01 V1 AUO 31.5 1920×1080
T315HW02 V0 AUO 31.5 1920×1080
T315HW02 V1 AUO 31.5 1920×1080
T315HW04 V9 AUO 31.5 1920×1080
T315HW05 V0 AUO 31.5 1920×1080
T315HW05 V2 AUO 31.5 1920×1080
T315HW05 V3 AUO 31.5 1920×1080
T315HW05 V5 AUO 31.5 1920×1080
T315HW07 V2 AUO 31.5 1920×1080
T315HW07 V6 AUO 31.5 1920×1080
