| Part Number | STCG057QVLAM-G02-S |
| Mark | Kyocera |
| Gréisst | 5.7 |
| Applikatioun | Industrial |
| Opléisung | 320×240 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 700:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | Parallel |
| Mark | Kyocera |
| Modell | STCG057QVLAM-G02-S |
| diagonal Gréisst | 5.7 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 320(RGB)×240 [QVGA] 70PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 115.2(H)×86.4(V) mm |
| kontur dim. | 144(H)×104.8(V) ×13.5(D) mm |
| bezel Beräich | 118.4(H)×89.0(V) mm |
| Behandlung | Glare (Haze 0%) |
| luminance | 500 cd/m² (Typ.) |
| Kontrast Verhältnis | 700:1 (Typ.) (TM) |
| Vue Richtung | - |
| Äntwert Zäit | 10/25 (Typ.)(Tr/Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥5) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Ënnerstëtzung Faarf | 262K 60% NTSC |
| Liichtquell | WLED , 40K hours , W/O Driver |
| Gewiicht | 158g (Typ.) |
| entworf fir | Industrial |
| Frame Taux | - |
| Touch Panel | Without |
| Interface Typ | Parallel RGB (1 ch, 6-bit) , 33 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
