| Part Number | KG057QV1CA-G020 |
| Mark | Kyocera |
| Gréisst | 5.7 |
| Applikatioun | IA |
| Opléisung | 320×240 |
| Zesummesetzung | LCM |
| Hellegkeet | 260 |
| CR | 4:1 |
| Faarwen | Monochrome |
| Géigeliicht | CCFL |
| Interface | Parallel Data |
| Panel Mark | Kyocera |
| Panel Modell | KG057QV1CA-G020 |
| Panel Typ | STN-LCD , LCM |
| Panel Gréisst | 5.7 inch |
| Resolutioun | 320×240 , QVGA |
| Display Modus | STN, Blue mode (Negative), Transmissive |
| aktiv Beräich | 115.18×86.38 mm |
| skizzéieren | 144×104.8×13.2 mm |
| Uewerfläch | Glare (Haze 0%) |
| Hellegkeet | 260 cd/m² (Typ.) |
| Kontrast Verhältnis | 4:1 (Typ.) |
| weisen Faarwen | Monochrome |
| Äntwert Zäit | 380/120 (Typ.)(Tr/Td) |
| Vue Wénkel | 45/45/20/40 (Typ.)(CR≥2)(L/R/U/D) |
| Frequenz | 75Hz |
| Lampe Typ | 1 pcsCCFLOptional |
| Signal Interface | Parallel Data (4-bit), 20 pins |
| Input Volt | 3.3/5.0V (Typ.)(VDD) |
| Applikatioun | IA |
