| Part Number | SN270CS01-1 |
| Mark | HKC |
| Gréisst | 27.0 |
| Applikatioun | Desktop Monitor |
| Opléisung | 1920×1080 |
| Zesummesetzung | CELL, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | No B/L |
| Interface | LVDS |
| Fabrikant beschwéiert | HKC |
| Modell Numm | SN270CS01-1 |
| Écran Gréisst | 27.0 inch |
| Écran Typ | CELL, a-Si TFT-LCD |
| Pixel Zuel | 1920(RGB)×1080 (FHD) 81PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 597.888 × 336.312 (H×V) |
| Kontur (mm) | 606.088 × 349.212 × 1.27 (H×V×D) |
| Bezel Beräich (mm) | - |
| Behandlung | Antiglare (Haze 25%), Hard coating (3H) |
| luminance | 0 cd/m² |
| Kontrast Verhältnis | 1000 : 1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Äntwert | 14 (Typ.)(G to G) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | HIS, Normally Black, Transmissive |
| Glas deck | 0.50+0.50 mm |
| transmissivitéit | 5.7% (Typ.) |
| Faarfdéift | 16.7M 72% NTSC |
| mass | 670g (Typ.) |
| benotzt fir | Desktop Monitor |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Chauffer ic Lëscht | Built-in COF 8 source chips |
| Signal Typ | LVDS (2 ch, 8-bit) , Connector 30 pins |
| Spannungsversuergung | 5.0V (Typ.) |
| max. Bewäertungen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| LM270WF4-TLA1 | LG Display | 27.0 | 1920×1080 |
| LM270WF5-SLM1 | LG Display | 27.0 | 1920×1080 |
| LM270WQ1-SDB3 | LG Display | 27.0 | 2560×1440 |
| LM270WQ1-SDDA | LG Display | 27.0 | 2560×1440 |
| LM270WQ3-SLA1 | LG Display | 27.0 | 2560×1440 |
| LM270WR2-SPA1 | LG Display | 27.0 | 3840×2160 |
| LTM270DL06 | Samsung | 27.0 | 2560×1440 |
| M270H3-L01 | Innolux | 27.0 | 1920×1080 |
| M270HVN02.0 | AUO | 27.0 | 1920×1080 |
| M270HW01 V1 | AUO | 27.0 | 1920×1080 |
