| Part Number | S50HW-YB06 |
| Mark | Samsung |
| Gréisst | 50 |
| Applikatioun | LCTV |
| Opléisung | 1365×768 |
| Zesummesetzung | PDP |
| Hellegkeet | 630 |
| CR | 5000:1 |
| Faarwen | 1.07B |
| Géigeliicht | self |
| Interface | LVDS |
| Panel Mark | SAMSUNG SDI |
| Panel Modell | S50HW-YB06 |
| Panel Typ | PDP , PDP |
| Panel Gréisst | 50 inch |
| Resolutioun | 1365(RGB)×768 , WXGA |
| aktiv Beräich | 1105.65×622.08 mm |
| skizzéieren | 1175.4×688 mm |
| Uewerfläch | |
| Hellegkeet | 630 cd/m² (Typ.) |
| Kontrast Verhältnis | 5000 : 1 (Typ.) |
| weisen Faarwen | 1.07B (10-bit) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signal Interface | LVDS (1 ch, 10-bit) + SPI, 30 pins |
| rohs: | |
| Applikatioun | LCTV |
