| Part Number | S035V04-T |
| Mark | CDTECH |
| Gréisst | 3.5 |
| Applikatioun | Industrial Handheld |
| Opléisung | 480×640 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 262K |
| Géigeliicht | 8S1P |
| Interface | Parallel |
| Panel Mark | CDTECH |
| Panel Modell | S035V04-T |
| Panel Gréisst | 3.5" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 480(RGB)×640, VGA, 228PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 53.28(W)×71.04(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 64(W)×85(H) ×5(D) mm |
| Uewerfläch | - |
| Hellegkeet | 650 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.) (TM) |
| Vue Wénkel | 65/65/55/65 (Typ.)(CR≥10) |
| Display Modus | TN, Normally White, Transmissive |
| beschte Vue op | 9 o'clock |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| weisen Faarwen | 262K 50% NTSC |
| Lampe Typ | 8S1P WLED , 25K hours , Without Driver |
| Frequenz | 60Hz |
| Touchscreens | 4-wire Resistive Touch |
| Panel Gewiicht | TBD |
| Applikatioun | Industrial Handheld & PDA |
| Signal Interface | Parallel RGB (1 ch, 6-bit) , 39 pins FPC |
| Input Volt | 3.3/3.3V (Typ.)(VCC/IOVCC) |
| Ëmwelt | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
