| Part Number | PJ101IA-01A |
| Mark | Innolux |
| Gréisst | 10.1 |
| Applikatioun | PAD |
| Opléisung | 1280×800 |
| Zesummesetzung | LCM |
| Hellegkeet | 450 |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | MIPI |
| Panel Mark | INNOLUX |
| Panel Modell | PJ101IA-01A |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 10.1 inch |
| Resolutioun | 1280(RGB)×800 , WXGA |
| Display Modus | IPS, Normally Black, Transmissive |
| aktiv Beräich | 216.96×135.36 mm |
| skizzéieren | 227.56×148.2×4.65 mm |
| Uewerfläch | Hard coating |
| Hellegkeet | 450 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193150% |
| Äntwert Zäit | 35 (Typ.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLED |
| Signal Interface | MIPI (4 data lanes), 40 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | PAD |
| B079XAN02.0 CELL | AUO | 7.9 | 768×1024 |
| CLAA101FP01 | CPT | 10.1 | 1920×1200 |
| HJ070IA-01I | Innolux | 7.0 | 1024×600 |
| HV070WX2-100 | HYDIS | 7.0 | 800×1280 |
| LD070WU1-SM01 | LG Display | 7.0 | 1200×1920 |
| LD089WU1-SM01 | LG Display | 8.9 | 1920×1200 |
| LP116WH4-SLA1 | LG Display | 11.6 | 1366×768 |
| LQ104X2LX05A | SHARP | 10.4 | 1024×768 |
| M101NWWB R6 | IVO | 10.1 | 1280×800 |
| N101ICE-G63 | Innolux | 10.1 | 1280×800 |
