| Part Number | P101DCZ-3Z0 |
| Mark | Innolux |
| Gréisst | 10.1 |
| Applikatioun | Pad & Tablet |
| Opléisung | 800×1280 |
| Zesummesetzung | CELL , a-Si TFT-LC |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | No B/L |
| Interface | MIPI |
| Fabrikant beschwéiert | Innolux |
| Écran Gréisst | 10.1 inch |
| Pixel Zuel | 800(RGB)×1280 (WXGA) 150PPI |
| aktiv Beräich (mm) | 135.36 × 216.576 (H×V) |
| Bezel Beräich (mm) | - |
| luminance | 0 cd/m² |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| gutt Vue op | Symmetry |
| Glas deck | - |
| Faarfdéift | 16.7M 59% NTSC |
| mass | - |
| Erfrëschungsrate | 60Hz |
| Signal Typ | MIPI (4 data lanes) , 40 pins Connector |
| Spannungsversuergung | 3.3/5.8/-5.8V (Typ.)(VDDIN/AVDD/AVEE) |
| max. Bewäertungen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Modell Numm | P101DCZ-3Z0 |
| Écran Typ | CELL , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | - |
| Behandlung | Clear, Hard coating (3H) |
| Kontrast Verhältnis | 800 : 1 (Typ.) (TM) |
| Äntwert | 25 (Typ.)(Tr+Td) ms |
| Aarbecht Modus | AAS, Normally Black, Transmissive |
| transmissivitéit | 4.73% (Typ.)(with Polarizer) |
| benotzt fir | Pad & Tablet |
| touchscreen | Without |
| B101UAN02.1 | AUO | 10.1 | 1920×1200 |
| HJ101IA-01I | Innolux | 10.1 | 1280×800 |
| HSD100IFW1-F01 | HannStar | 10.1 | 1024×600 |
| LP101WH1-TLA3 | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLA3 | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLAF | LG Display | 10.1 | 1366×768 |
| LTL101AL03-W01 | Samsung | 10.1 | 1280×800 |
| N101BGE-L21 | Innolux | 10.1 | 1366×768 |
| N101ICE-G63 | Innolux | 10.1 | 1280×800 |
| N101N6-L02 | Innolux | 10.1 | 1024×576 |
