| Part Number | NV116WHM-A23 |
| Mark | BOE |
| Gréisst | 11.6 |
| Applikatioun | Laptop |
| Opléisung | 1366×768 |
| Zesummesetzung | a-Si TFT-LCD , Assem |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 262K |
| Géigeliicht | 6S4P |
| Interface | |
| Panel Mark | BOE |
| Panel Gréisst | 11.6" |
| Resolutioun | 1366(RGB)×768, WXGA, 135PPI |
| Affichage Beräich | 256.125(W)×144(H) mm |
| Kontur Gréisst | 287.7(W)×185.6(H) ×4.05(D) mm |
| Hellegkeet | 200 cd/m² (Typ.) |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 262K 50% NTSC |
| Frequenz | 60Hz |
| Form Stil | Slim (PCBA Flat, T≤3.2mm) |
| Panel Modell | NV116WHM-A23 (BOE0744) |
| Panel Typ | a-Si TFT-LCD , Assembly |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | Anti-Scatter, Hard coating (7H) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Display Modus | - |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Lampe Typ | 6S4P WLED , 15K hours , With LED Driver |
| Touchscreens | PCAP, Optical Bonding |
| Applikatioun | Laptop |
| B116XAN03.0 HW3A | AUO | 11.6 | 1366×768 |
| B116XAN03.1 HW1A | AUO | 11.6 | 1366×768 |
| B116XAT03.1 | AUO | 11.6 | 1366×768 |
| LP116WH1-TLP1 | LG Display | 11.6 | 1366×768 |
| LP116WH4-SLN1 | LG Display | 11.6 | 1366×768 |
| M116NWR1 R1 | IVO | 11.6 | 1366×768 |
| M116NWR1 R3 | IVO | 11.6 | 1366×768 |
| M116NWR6 R0 | IVO | 11.6 | 1366×768 |
| N116BGE-EB2 Rec.C3 | Innolux | 11.6 | 1366×768 |
| N116BGE-L42 | Innolux | 11.6 | 1366×768 |
