| Part Number | NL192120AC25-02 |
| Mark | NLT |
| Gréisst | 22.5 |
| Applikatioun | DMPC |
| Opléisung | 1920×1200 |
| Zesummesetzung | LCM |
| Hellegkeet | 420 |
| CR | 800:1 |
| Faarwen | 1.07B |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | NEC |
| Panel Modell | NL192120AC25-02 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 22.5 inch |
| Resolutioun | 1920(RGB)×1200 , WUXGA |
| Display Modus | UA-SFT, Normally Black, Transmissive |
| aktiv Beräich | 483.84×302.4 mm |
| skizzéieren | 542×362 mm |
| Uewerfläch | Antiglare, Hard coating (2H) |
| Hellegkeet | 420 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) |
| weisen Faarwen | 1.07B (10-bit), Adobe97% |
| Äntwert Zäit | 6/6 (Typ.)(Tr/Td) |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 120Hz |
| Lampe Typ | 12 pcsCCFLEmbedded (Inverter) |
| Signal Interface | LVDS (4 ch, 10-bit), 104 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | DMPC |
