| Part Number | NL192108BC18-06F |
| Mark | NLT |
| Gréisst | 15.6 |
| Applikatioun | Industrial Outdoor H |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 750:1 |
| Faarwen | 16.7M |
| Géigeliicht | 4 strings WLED , 50K hours , No Driver |
| Interface | eDP |
| Fabrikant beschwéiert | NLT |
| Modell Numm | NL192108BC18-06F |
| Écran Gréisst | 15.6 inch |
| Écran Typ | LCM , a-Si TFT-LCD |
| Pixel Zuel | 1920(RGB)×1080 (FHD) 141PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 344.16 × 193.59 (H×V) |
| Kontur (mm) | 363.8 × 215.9 × 16.2 (H×V×D) |
| Bezel Beräich (mm) | 347.55 × 196.75 (H×V) |
| Behandlung | Antiglare, Hard coating (3H) |
| luminance | 1500 cd/m² (Typ.) |
| Kontrast Verhältnis | 750 : 1 (Typ.) (TM) |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥10) |
| Äntwert | 15/15 (Typ.)(Tr/Td) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | UA-SFT, Normally Black, Transmissive |
| Faarfdéift | 16.7M 40% NTSC |
| mass | 1.05/1.15Kgs (Typ./Max.) |
| benotzt fir | Industrial Outdoor High Brightness |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Signal Typ | eDP (2 Lanes) , HBR1 (2.7G/lane) , 40 pins Connector |
| Spannungsversuergung | 3.3V (Typ.) |
| max. Bewäertungen | Storage Temp.: -40 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
