| Part Number | NL10276AC30-07 |
| Mark | NLT |
| Gréisst | 15.0 |
| Applikatioun | DMPC |
| Opléisung | 1024×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 400 |
| CR | 300:1 |
| Faarwen | 16.7M |
| Géigeliicht | CCFL |
| Interface | TTL |
| Panel Mark | NEC |
| Panel Modell | NL10276AC30-07 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 15.0 inch |
| Resolutioun | 1024(RGB)×768 , XGA |
| Display Modus | Normally Black, Transmissive |
| aktiv Beräich | 304.128×228.096 mm |
| skizzéieren | 330×256×30 mm |
| Uewerfläch | Hard coating (2H) |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 300:1 (Typ.) |
| weisen Faarwen | 16.7M (6-bit + Hi-FRC), CIE193160% |
| Äntwert Zäit | 10/10 (Typ.)(Tr/Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 8 pcsCCFLEmbedded (Inverter) |
| Signal Interface | TTL (2 ch, 8-bit), 75 pins |
| Input Volt | 5.0V (Typ.) |
| Applikatioun | DMPC |
