MT215DW01 V.0

MT215DW01 V.0
MT215DW01 V.0
MT215DW01 V.0 thumb MT215DW01 V.0 thumb
Mark
Innolux
Gréisst
21.5
Applikatioun
DMPC
Opléisung
1920×1080
Zesummesetzung
LCM
Hellegkeet
300
CR
1000:1
Faarwen
16.7M
Backlight
CCFL
Interface
LVDS
In Stock
7992
Spezifikatioune

Part Number MT215DW01 V.0
MarkInnolux
Gréisst21.5
ApplikatiounDMPC
Opléisung1920×1080
ZesummesetzungLCM
Hellegkeet300
CR1000:1
Faarwen16.7M
GéigeliichtCCFL
InterfaceLVDS
Panel MarkINNOLUX
Panel ModellMT215DW01 V.0
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst21.5 inch
Resolutioun1920(RGB)×1080 , FHD
Display ModusTN, Normally White, Transmissive
aktiv Beräich476.64×268.11 mm
skizzéieren495.6×292.2×16.85 mm
UewerflächAntiglare, Hard coating (3H)
Hellegkeet300 cd/m² (Typ.)
Kontrast Verhältnis1000:1 (Typ.)
weisen Faarwen16.7M (6-bit + Hi-FRC), CIE193172%
Äntwert Zäit1.5/3.5 (Typ.)(Tr/Td)
Vue Wénkel85/85/80/80 (Min.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe Typ4 pcsCCFLWithout Driver
Signal InterfaceLVDS (2 ch, 8-bit), 30 pins
Input Volt5.0V (Typ.)
ApplikatiounDMPC
Famill Modell
G215HVN01.0 S03 AUO 21.5 1920×1080
LC215DT4A PANDA 21.5 1920×1080
LM215WF3-SLA2 LG Display 21.5 1920×1080
LM215WF5-SLA1 LG Display 21.5 1920×1080
M215HGE-L21 Innolux 21.5 1920×1080
M215HGK-L30 Innolux 21.5 1920×1080
M215HW02 V0 AUO 21.5 1920×1080
MT215DW01 V.0 Innolux 21.5 1920×1080
MT215DW01 V.1 Innolux 21.5 1920×1080
RX215-C10 ROGIN 21.5 1920×1080
