| Part Number | MND307DA1-8 |
| Mark | CSOT |
| Gréisst | 13.3 |
| Applikatioun | Laptop |
| Opléisung | 2560×1600 |
| Zesummesetzung | LTPS TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1500:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | eDP |
| Panel Mark | CSOT |
| Panel Gréisst | 13.3" |
| Resolutioun | 2560(RGB)×1600, WQXGA, 227PPI |
| Affichage Beräich | 286.08(W)×178.8(H) mm |
| Kontur Gréisst | 291.08(W)×195.3(H) ×2.4(D) mm |
| Hellegkeet | 300 cd/m² (Typ.) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M 99% sRGB |
| Frequenz | 60Hz |
| Form Stil | Slim (PCBA Flat, T≤3.2mm) |
| Signal Interface | eDP (4 Lanes) , HBR1 (2.7G/lane) , 40 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Modell | MND307DA1-8 |
| Panel Typ | LTPS TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | Antiglare |
| Kontrast Verhältnis | 1500:1 (Typ.) (TM) |
| Display Modus | FFS, Normally Black, Transmissive |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Lampe Typ | WLED , 15K hours , With LED Driver |
| Touchscreens | Without |
| Applikatioun | Laptop |
| B133HAN02.5 | AUO | 13.3 | 1920×1080 |
| B133XW04 V0 | AUO | 13.3 | 1366×768 |
| G133I1-L01 | Innolux | 13.3 | 1280×800 |
| HV133WX1-100 | HYDIS | 13.3 | 1280×800 |
| LP133WH1-TLB1 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLN4 | LG Display | 13.3 | 1366×768 |
| LP133X7-F2IB | LG Display | 13.3 | 1024×768 |
| LT133X8-122 | Samsung | 13.3 | 1024×768 |
| LTN133AT01-001 | Samsung | 13.3 | 1280×800 |
| LTN133AT23-001 | Samsung | 13.3 | 1366×768 |
