| Part Number | M238KCJ-L5B |
| Mark | Innolux |
| Gréisst | 23.8 |
| Applikatioun | Desktop Monitor |
| Opléisung | 2560×1440 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | Innolux |
| diagonal Gréisst | 23.8 inch |
| Pixel Format | 2560(RGB)×1440 [Quad-HD] 123PPI |
| aktiv Beräich | 525.696(H)×295.704(V) mm |
| bezel Beräich | - |
| luminance | 300 cd/m² (Typ.) |
| Vue Richtung | Symmetry |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Ënnerstëtzung Faarf | 16.7M 95% DCI-P3 |
| Gewiicht | 2.40/2.52Kgs (Typ./Max.) |
| Frame Taux | 60Hz |
| Interface Typ | LVDS (4 ch, 8-bit) , 92 pins Connector |
| Stroumversuergung | 10.0V (Typ.) |
| Ëmwelt | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Modell | M238KCJ-L5B |
| Typ | a-Si TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 536.3(H)×313.7(V) ×14.9(D) mm |
| Behandlung | Antiglare (Haze 25%), Hard coating (3H) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Äntwert Zäit | 8/7 (Typ.)(Tr/Td) |
| Betribssystemer Modus | AAS, Normally Black, Transmissive |
| Liichtquell | WLED , 30K hours , W/O Driver |
| entworf fir | Desktop Monitor |
| Touch Panel | Without |
