| Part Number | M238DTN01.3 |
| Mark | AUO |
| Gréisst | 23.8 |
| Applikatioun | Desktop Monitor Gami |
| Opléisung | 2560×1440 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | AUO |
| Modell | M238DTN01.3 |
| diagonal Gréisst | 23.8 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 2560(RGB)×1440 [Quad-HD] 123PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 526.85(H)×296.35(V) mm |
| kontur dim. | 536.9(H)×313.89(V) ×12.7(D) mm |
| bezel Beräich | - |
| Behandlung | Antiglare, Hard coating (3H) |
| luminance | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Richtung | - |
| Äntwert Zäit | 3.5/1.5 (Typ.)(Tr/Td) |
| Vue Wénkel | 85/85/80/80 (Typ.)(CR≥10) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 72% NTSC |
| Liichtquell | WLED [16S4P] , 30K hours , W/O Driver |
| Gewiicht | 2.27Kgs (Typ.) |
| entworf fir | Desktop Monitor Gaming |
| Frame Taux | 144Hz |
| Touch Panel | Without |
| Interface Typ | LVDS (8 ch, 8-bit) , 130 pins Connector |
| Stroumversuergung | 12V (Typ.) |
| Ëmwelt | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
