| Part Number | M080AWT8 R1 |
| Mark | IVO |
| Gréisst | 8.0 |
| Applikatioun | Automotive Display |
| Opléisung | 1024×600 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | IVO |
| Modell | M080AWT8 R1 |
| diagonal Gréisst | 8.0 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1024(RGB)×600 [WSVGA] 148PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 176.64(H)×99.36(V) mm |
| kontur dim. | 192.8(H)×116.9(V) ×8.35(D) mm |
| bezel Beräich | 178.84(H)×101.56(V) mm |
| Behandlung | Antiglare |
| luminance | 670 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Vue Richtung | 6 o'clock |
| Äntwert Zäit | 16 (Typ.)(Tr+Td) |
| Vue Wénkel | 75/75/70/75 (Typ.)(CR≥10) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Ënnerstëtzung Faarf | 262K/16.7M 72% NTSC |
| Liichtquell | WLED [3S7P] , 30K hours , W/O Driver |
| Gewiicht | 240g (Max.) |
| entworf fir | Automotive Display |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | LVDS (1 ch, 6/8-bit) , 40 pins FPC |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C |
