Samsung LTN156AT01-B01 Dateblat, Spezifizéierung, Aktien, Applikatioun www.looklcd-lu.com
LookLCD LookLCD


LTN156AT01-B01

LTN156AT01-B01
LTN156AT01-B01
LTN156AT01-B01 thumb LTN156AT01-B01 thumb
Mark
Samsung
Gréisst
15.6
Applikatioun
NBPC
Opléisung
1366×768
Zesummesetzung
LCM
Hellegkeet
220
CR
600:1
Faarwen
262K
Backlight
CCFL
Interface
LVDS
In Stock
1797
Spezifikatioune

Part Number LTN156AT01-B01
MarkSamsung
Gréisst15.6
ApplikatiounNBPC
Opléisung1366×768
ZesummesetzungLCM
Hellegkeet220
CR600:1
Faarwen262K
GéigeliichtCCFL
InterfaceLVDS
Panel MarkSAMSUNG
Panel ModellLTN156AT01-B01 10 Compatible model
Panel Typ a-Si TFT-LCD , LCM
Panel Gréisst15.6 inch
Resolutioun1366(RGB)×768 , WXGA
Display ModusTN, Normally White, Transmissive
aktiv Beräich344.232×193.536 mm
skizzéieren359.3×209.5×6.2 mm
Form StilWedge (PCBA Bent, Depth ≥5.2mm)
UewerflächGlare (Haze 0%), Hard coating (3H)
Hellegkeet220 cd/m² (Typ.)
Kontrast Verhältnis600:1 (Typ.)
weisen Faarwen262K (6-bit), CIE193160%
Äntwert Zäit25/35 (Typ./Max.)(Tr+Td)
Vue Wénkel40/40/15/30 (Typ.)(CR≥10)(L/R/U/D)
Frequenz60Hz
Lampe Typ1 pcsCCFLWithout Driver
Signal InterfaceLVDS (1 ch, 6-bit), 30 pins
Input Volt3.3V (Typ.)
ApplikatiounNBPC
Famill Modell
LTN156AT01-A01 Samsung 15.6 1366×768
LTN156AT01-B02 Samsung 15.6 1366×768
LTN156AT01-D02 Samsung 15.6 1366×768
LTN156AT01-H01 Samsung 15.6 1366×768
LTN156AT02-A11 Samsung 15.6 1366×768
LTN156AT02-D02 Samsung 15.6 1366×768
LTN156AT02-W01 Samsung 15.6 1366×768
LTN156AT05-S01 Samsung 15.6 1366×768
LTN156AT05-W01 Samsung 15.6 1366×768
LTN156AT20-P01 Samsung 15.6 1366×768
