| Part Number | LTN154BT05-001 |
| Mark | Samsung |
| Gréisst | 15.4 |
| Applikatioun | NBPC |
| Opléisung | 1440×900 |
| Zesummesetzung | LCM |
| Hellegkeet | 250 |
| CR | 400:1 |
| Faarwen | 262K |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | SAMSUNG |
| Panel Modell | LTN154BT05-001 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 15.4 inch |
| Resolutioun | 1440(RGB)×900 , WXGA+ |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 331.56×207.225 mm |
| skizzéieren | 344×222×6.5 mm |
| Form Stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Uewerfläch | Antiglare (Haze 40%), Hard coating (3H) |
| Hellegkeet | 250 cd/m² (Typ.) |
| Kontrast Verhältnis | 400:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193145% |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 55/55/45/45 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 1 pcsCCFLWithout Driver |
| Signal Interface | LVDS (2 ch, 6-bit), 30 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | NBPC |
| CLAA154WB08AN | CPT | 15.4 | 1280×800 |
| LP154W01-A3 | LG Display | 15.4 | 1280×800 |
| LP154W01-TLAA | LG Display | 15.4 | 1280×800 |
| LP154WE2-TLB1 | LG Display | 15.4 | 1680×1050 |
| LP154WX7-TLA1 | LG Display | 15.4 | 1280×800 |
| LTN154BT02-004 | Samsung | 15.4 | 1440×900 |
| LTN154BT05-001 | Samsung | 15.4 | 1440×900 |
| LTN154BT05-D01 | Samsung | 15.4 | 1440×900 |
| LTN154BT07-S01 | Samsung | 15.4 | 1440×900 |
| QD15TL04 Rev.05 | QDI | 15.4 | 1280×800 |
| B154EW02 V2 | AUO | 15.4 | 1280×800 |
| B173HW01 V5 | AUO | 17.3 | 1920×1080 |
| CLAA154WB04A | CPT | 15.4 | 1280×800 |
| HSD140PNW1-B00 | HannStar | 14.0 | 1600×900 |
| LP154WX5-TLA1 | LG Display | 15.4 | 1280×800 |
| LQ084S1DH10 | SHARP | 8.4 | 800×600 |
| LTN140AT07-401 | Samsung | 14.0 | 1366×768 |
| LTN154X3-L06-J | Samsung | 15.4 | 1280×800 |
| LTN173HT02-C01 | Samsung | 17.3 | 1920×1080 |
| N150P5-L02 | Innolux | 15.0 | 1400×1050 |
