| Part Number | LTM340YP02 |
| Mark | Samsung |
| Gréisst | 34 |
| Applikatioun | DMPC |
| Opléisung | 3440×1440 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 3000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | eDP |
| Panel Mark | SAMSUNG |
| Panel Modell | LTM340YP02 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 34 inch |
| Resolutioun | 3440(RGB)×1440 |
| Display Modus | PVA, Normally Black, Transmissive |
| aktiv Beräich | 799.8×334.8 mm |
| skizzéieren | 811.5×357×18.1 mm |
| Uewerfläch | Antiglare (Haze 2.3%), Hard coating (2H) |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 3000:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), sRGB99% |
| Äntwert Zäit | 14 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 4 stringsWLEDWithout Driver |
| Signal Interface | eDP (4 Lanes), 50 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | DMPC |
