| Part Number | LTM238HP01 |
| Mark | SAMSUNG |
| Gréisst | 23.8 |
| Applikatioun | Desktop Monitor |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 3000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Fabrikant beschwéiert | SAMSUNG |
| Modell Numm | LTM238HP01 |
| Écran Gréisst | 23.8 inch |
| Écran Typ | LCM , a-Si TFT-LCD |
| Pixel Zuel | 1920(RGB)×1080 (FHD) 92PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 527.04 × 296.46 (H×V) |
| Kontur (mm) | - |
| luminance | - |
| Kontrast Verhältnis | 3000 : 1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Äntwert | 14 (Typ.)(G to G) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | PVA, Normally Black, Transmissive |
| Faarfdéift | 16.7M 72% NTSC |
| mass | - |
| benotzt fir | Desktop Monitor |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Signal Typ | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Spannungsversuergung | 5.0V (Typ.) |
| max. Bewäertungen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
