| Part Number | LTM08C355S |
| Mark | TOSHIBA |
| Gréisst | 8.4 |
| Applikatioun | NBPC |
| Opléisung | 800×600 |
| Zesummesetzung | LCM |
| Hellegkeet | 120 |
| CR | 250:1 |
| Faarwen | 262K |
| Géigeliicht | CCFL |
| Interface | TTL |
| Panel Mark | TOSHIBA |
| Panel Modell | LTM08C355S |
| Panel Typ | LTPS TFT-LCD , LCM |
| Panel Gréisst | 8.4 inch |
| Resolutioun | 800(RGB)×600 , SVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 170.4×127.8 mm |
| skizzéieren | 200.3×140.3 mm |
| Uewerfläch | |
| Hellegkeet | 120 cd/m² (Typ.) |
| Kontrast Verhältnis | 250:1 (Typ.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 50/50 (Max.)(Tr/Td) |
| Vue Wénkel | |
| Frequenz | 60Hz |
| Lampe Typ | 1 pcsCCFLWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 30 pins |
| Input Volt | 3.3V (Typ.)(VDD) |
| Applikatioun | NBPC |
