| Part Number | TM121XG-02L01 |
| Mark | SANYO |
| Gréisst | 12.1 |
| Applikatioun | NBPC |
| Opléisung | 1024×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 150 |
| CR | 300:1 |
| Faarwen | 262K |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | TORISAN |
| Panel Modell | TM121XG-02L01 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 12.1 inch |
| Resolutioun | 1024(RGB)×768 , XGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 245.76×184.32 mm |
| skizzéieren | 275×199×5.7 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 150 cd/m² (Typ.) |
| Kontrast Verhältnis | 300:1 (Typ.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 32/13 (Typ.)(Tr/Td) |
| Vue Wénkel | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 1 pcsCCFLWithout Driver |
| Signal Interface | LVDS (1 ch, 6-bit), 20 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | NBPC |
| LQ121S1LG41 | SHARP | 12.1 | 800×600 |
| LTD121EC5V | TOSHIBA | 12.1 | 1024×768 |
| LTD121EXFV | TOSHIBA | 12.1 | 1280×768 |
| LTD121KC6K | TOSHIBA | 12.1 | 1024×768 |
| LTN121AT08 | Samsung | 12.1 | 1280×800 |
| LTN121AT10-301 | Samsung | 12.1 | 1280×800 |
| LTN121XJ-L07 | Samsung | 12.1 | 1024×768 |
| NL10276BC24-19D | NLT | 12.1 | 1024×768 |
| TM121XG-02L01 | SANYO | 12.1 | 1024×768 |
| TM121XG-02L10 | SANYO | 12.1 | 1024×768 |
| G075ADE-T01 | Innolux | 7.5 | 1200×900 |
| LP154WE2-TLA7 | LG Display | 15.4 | 1680×1050 |
| LTD121EDKP | TOSHIBA | 10.4 | 1024×768 |
| LTD121EWPF | TOSHIBA | 12.1 | 1280×800 |
| LTN140AT02-C02 | Samsung | 14.0 | 1366×768 |
| LTN156AT05-B01 | Samsung | 15.6 | 1366×768 |
| LTN170CT08-001 | Samsung | 17.0 | 1920×1200 |
| N133BGE-L41 | Innolux | 13.3 | 1366×768 |
| N140BGE-EA3 | Innolux | 14.0 | 1366×768 |
| N140BGE-L23 | Innolux | 14.0 | 1366×768 |
