| Part Number | LTI700HD03 |
| Mark | Samsung |
| Gréisst | 70 |
| Applikatioun | PID |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM |
| Hellegkeet | 450 |
| CR | 2000:1 |
| Faarwen | 16.7M |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | SAMSUNG |
| Panel Modell | LTI700HD03 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 70 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | S-PVA, Normally Black, Transmissive |
| aktiv Beräich | 1549.44×871.56 mm |
| skizzéieren | 1630×952×83.6 mm |
| Uewerfläch | Antiglare (Haze 6.7%), Hard coating (3H) |
| Hellegkeet | 450 cd/m² (Typ.) |
| Kontrast Verhältnis | 2000:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193177% |
| Äntwert Zäit | 10/6 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 64 pcsCCFLEmbedded (Inverter) |
| Signal Interface | LVDS (2 ch, 8-bit), 51 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | PID |
