| Part Number | LTA320HJ06-W |
| Mark | SAMSUNG |
| Gréisst | 32.0 |
| Applikatioun | TV Sets |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 5000:1 |
| Faarwen | 1.07B |
| Géigeliicht | WLED , 35K hours |
| Interface | LVDS |
| Fabrikant beschwéiert | SAMSUNG |
| Écran Gréisst | 32.0 inch |
| Pixel Zuel | 1920(RGB)×1080 (FHD) 69PPI |
| aktiv Beräich (mm) | 698.4 × 392.85 (H×V) |
| Bezel Beräich (mm) | 705.4 × 400 (H×V) |
| luminance | 350 cd/m² (Typ.) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| gutt Vue op | Symmetry |
| Faarfdéift | 1.07B 70% NTSC |
| mass | 5.00/5.5Kgs (Typ./Max.) |
| Erfrëschungsrate | 60Hz |
| Signal Typ | LVDS (2 ch, 10-bit) , 61 pins Connector |
| Spannungsversuergung | 12.0V (Typ.) |
| max. Bewäertungen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Modell Numm | LTA320HJ06-W |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 726.2 × 422.9 × 27.9 (H×V×D) |
| Behandlung | Antiglare (Haze 2%), Hard coating (2H) |
| Kontrast Verhältnis | 5000 : 1 (Typ.) (TM) |
| Äntwert | 8 (Typ.)(G to G) ms |
| Aarbecht Modus | SPVA, Normally Black, Transmissive |
| benotzt fir | TV Sets |
| touchscreen | Without |
| LTA320AN01-C | Samsung | 31.5 | 1366×768 |
| LTA320AN01-W | Samsung | 31.5 | 1366×768 |
| LTA320AN12 | Samsung | 31.5 | 1366×768 |
| LTA320AP16 | Samsung | 31.5 | 1366×768 |
| LTA320HA02 | Samsung | 31.5 | 1920×1080 |
| LTA320HA04 | Samsung | 31.5 | 1920×1080 |
| LTA320HN02-W | Samsung | 31.5 | 1920×1080 |
| LTA320HN03-W | Samsung | 31.5 | 1920×1080 |
| LTA320HN04-W | Samsung | 31.5 | 1920×1080 |
| LTA320WT-L16 | Samsung | 31.5 | 1366×768 |
